Rohde & Schwarz has expanded its oscilloscope range with the launch of the R&S RTB 2, an upgraded version of the highly successful R&S RTB2000. Known for introducing features like touchscreen operation and 10-bit vertical resolution at an entry-level price point, the new R&S RTB 2 builds on this foundation with additional capabilities, including an integrated arbitrary waveform generator and 160 Mpts of segmented memory.
The R&S RTB 2 enhances its predecessor’s performance by incorporating several key upgrades. The newly added waveform generator can produce signals up to 25 MHz and support pattern speeds up to 50 Mbits/s, enabling users to simulate circuit stimuli or emulate missing components. The generator can also import waveforms from CSV files or oscilloscope captures and add noise to simulate real-world conditions. It includes pre-set patterns for popular protocols like I2C, SPI, UART, and CAN/LIN, offering further versatility for engineers.
A standout feature of the R&S RTB 2 is its all-in-one functionality, combining an oscilloscope, protocol analyzer, logic analyzer, waveform generator, and more, making it an ideal tool for engineers, hobbyists, and students working in space-constrained environments. The oscilloscope also includes an education mode with password protection and a built-in web server for remote viewing and control, making it perfect for educational purposes.
The R&S RTB 2’s enhanced memory capabilities, supporting up to 160 Mpoints in segmented mode, enable users to capture more data and perform in-depth troubleshooting. Additionally, the R&S RTB 2-PK1 software option bundle broadens the oscilloscope’s application range, providing enhanced performance.
Philip Diegmann, Vice President of Oscilloscopes at Rohde & Schwarz, commented, “With the R&S RTB 2, we’ve created a highly versatile instrument that delivers solid performance at an accessible price point. It combines features like 10-bit resolution and multi-functionality, offering engineers, students, and educators the tools they need for success.”
The R&S RTB 2 is being showcased at electronica 2024 in Munich (Hall A3.307) from November 12-15, 2024. It is now available through Rohde & Schwarz and select distributors. The oscilloscope comes in two and four-channel models, offering bandwidths of 70 MHz, 100 MHz, 200 MHz, and 300 MHz, with prices starting at €1,690 for the 2-channel 70 MHz model.
Rohde & Schwarz is a global technology company that has been advancing technological boundaries for 90 years. Based in Munich, the company operates across various sectors, including test and measurement, networks, cybersecurity, and technology systems. With 14,400 employees worldwide, Rohde & Schwarz generates annual revenues of €2.93 billion. The company is committed to ensuring technological independence and digital sovereignty for its industrial, regulatory, and government clients.
